Prompt
TECHNICAL ARCHITECTURAL BLUEPRINT DRAWING, CAD-style scaled floor plan and partial cross-section of a commercial oyster mushroom fruiting room. White background with crisp dark blue or black engineering lines, dimension strings, and architectural callouts. Professional structural engineering schematic. DIMENSIONED FLOOR PLAN (25 feet wide by 40 feet long): - Overall exterior building dimensions clearly labeled: 25'-0" WIDTH and 40'-0" LENGTH. - Interior wall thickness: 60mm (6-inch) PIR/PUF panels labeled "INSULATED WALL". - 7 parallel rack rows running vertically. Each row labeled: 23'-0" LONG x 4'-0" WIDE (with 2'-0" shelf depth per side). - 8 aisles between rows, each exactly 1'-0" WIDE, labeled clearly with dimension lines. - Side wall clearances: 2'-0" on left and right sides. - Bottom end (far end): EQUIPMENT ZONE measuring 8'-0" x 12'-0", subdivided into labeled boxes for: "AHU / CHILLER (6-8 TR)", "ELECTRICAL PANEL (VFD/PLC)", "WATER TANK & SOFTENER", and "HUMIDIFIER (2-5 kg/h)". - Doors: "PERSONNEL DOOR (3'-0")" and "MATERIAL DOOR (5'-0")" at the bottom end. - Drainage channels shown as dashed lines along both long walls with 2% slope arrows. INSET DETAIL: TOP-DOWN ZOOM of a single rack tier showing 23 cylindrical substrate bags per side at 1'-0" center-to-center spacing, labeled "10" BAGS @ 1'-0" O.C.". PARTIAL CROSS-SECTION (Side cutaway view) included on the right side showing vertical height dimensions: - Total clear height: 14'-0". - Floor base riser: 0'-6". - 6 growing tiers: each at 2'-0" vertical pitch, labeled "TIER 1" through "TIER 6". - Ceiling plenum: 1'-6" clearance. - Wall panels: 60mm thick. LEGEND BOX included with standard architectural symbols for: Supply Air Diffuser (circle with cross), Return Air Grille (dashed rectangle), Vaisala GMW90 Sensor (square with dot), LED Light Fixture (parallel lines), and DP Sensor (triangle). STYLE: Pristine architectural engineering CAD drawing, 8K resolution, ultra-detailed, precise geometric linework, white background, blue/black technical lines, no shading, just crisp blueprint-quality line art suitable for construction permitting.
